Operating Principle
IN-VESTA operates based on the photoacoustic effect — when the laser energy is absorbed by pigment particles (melanin or tattoo ink), it generates intense mechanical force that shatters these particles into micro-fragments. These micro-particles are then naturally eliminated by the lymphatic system, without damaging the epidermis or surrounding healthy tissue. Due to the ultra-short pulse duration, the laser energy does not produce thermal diffusion, which minimizes the risk of burns, scarring, or post-inflammatory hyperpigmentation (PIH).
Smart KTP Wavelength Conversion System
The device uses Potassium Titanyl Phosphate (KTP) crystals to convert 1064nm wavelengths into 532nm, broadening the treatment range — especially effective for shallow and light-colored pigmentations on the epidermis, which deeper wavelengths typically cannot reach.
Key Features of the IN-VESTA ND:YAG CRYSTAL
1. Treatment of Both Deep and Superficial Pigmentation
Deep dermal pigmentation: deep-seated melasma, congenital birthmarks, endogenous freckles.
Superficial pigmentation: epidermal melasma, age spots, post-inflammatory hyperpigmentation, surface-level freckles.
2. Safe Tattoo Removal (Cosmetic and Artistic)
Removes eyebrow, eyeliner, and lip tattoos with no scarring or pigment loss.
Eliminates body tattoos in black, green, red, etc., using high-power laser pulses that effectively break ink particles while preserving skin structure.
3. Skin Rejuvenation – Brightening and Evening Out Skin Tone
Improves dull skin, enlarged pores, and uneven complexion.
Stimulates natural collagen production, resulting in firmer, smoother, and more elastic skin.
Delivers rejuvenation results without downtime — ideal for busy clients.
Outstanding Advantages of IN-VESTA Technology
Medical-Grade Q-Switched Nd:YAG Technology
Uses ultra-short pulses (5–10 ns) with high peak power to selectively shatter melanin without causing burns, blisters, or peeling.
Effectively targets pigment while ensuring maximum safety for surrounding healthy tissue.
Multi-Wavelength Integration & Treatment Modes
1064nm: Ultra-short pulse duration allows high power output, targeting melanin from the epidermis to the dermis comprehensively and safely.
532nm: Shorter wavelength ideal for superficial pigment such as melasma, freckles, and brown spots.
In Toning: A dual-pulse is emitted within 100 microseconds after the first shot, enhancing photo-thermal effect for more effective and safer melasma treatment.
Multi Toning: Breaks one high-energy pulse into four smaller sub-pulses — gentle on sensitive or youthful freckled skin. Balances treatment efficacy and safety.
Long-Peel (300μs): Similar to Toning mode but starts with a stronger first pulse, followed by a dual pulse. The photo-thermal effect helps eliminate melasma without damaging the skin surface.
TREATMENT HANDPIECES
1. Standard Handpieces
Zoom Handpiece [2–10mm]:
Adjustable spot sizes from 2mm to 10mm (includes tips: 2–10mm).
Equipped with a smart sensor that detects spot size and displays it on the 10.2-inch screen for precise treatment control.
Collimated Handpiece [7mm]:
Fixed 7mm spot size optimized for toning procedures.
Special optical design ensures even energy distribution, minimizes energy loss, and delivers precise energy even on close-contact skin surfaces.
2. Optional Add-On Handpieces
Fractional 1064 Handpiece [7×7mm]:
Two versions: DOE and MLA
DOE version has 49 dots (7x7 array)
Spot size: 5 × 5 mm
Fractional 532 Handpiece [4×4mm]:
DOE design with 81 dots (9x9 array)
Spot size: 4 × 4 mm
660nm Handpiece [4.5mm]:
Energy output up to 150mJ
Targets shallow pigment issues like pigmented nevi or mixed melasma
Spot size: 4.5mm
Suggested 1–2 sessions every 2 weeks
595nm Handpiece [4.5mm]:
Energy output up to 200mJ
Ideal for vascular lesions, erythema, port wine stains, or inflammation-related skin issues
Spot size: 4.5mm
Suggested 3–5 sessions, 2 weeks apart depending on the condition
Why Invest in IN-VESTA for Your Spa, Clinic, or Aesthetic Center?
All-in-One Versatility: Treats melasma, tattoo removal, brightening, rejuvenation, and skin recovery in one device.
Fast Results – Cost-Effective: Short protocols with visible results after just 1–3 sessions.
No Consumables – Easy Maintenance: Simple to operate, maintain, and low-cost to run.
Adds Value – Elevates Prestige: Advanced technology enhances your brand and attracts high-end clientele.
Expert Training & Technical Support by Li’pointe: Ensures safe operation and maximized treatment outcomes.
